Werkstoffnummer

Werkstoffnummer
 according to DIN EN 10027-2

Material designation is a systematic and standardized method for identifying the specific properties of a material. This is particularly important in the metal industry, where there are a wide variety of materials that can vary greatly in composition and properties.
A material designation for steel, for example, provides information about the chemical composition, mechanical properties, and often also about the heat treatment of the steel.

A German material number, also known as a DIN EN Werkstoffnummer, is a five-digit number that is standardized in DIN EN 10027-2. It is unique and enables uniform identification of the material worldwide. Extended counting numbers that are listed from time to time are not generally used.

  • Material group: The first digits of the material number provide information about the material group. For example, the digits 1.4 stand for stainless steels.
  • Chemical composition: The following numbers provide information about the chemical composition of the steel. They can indicate, for example, the carbon content or the presence of certain alloying elements.
  • Condition symbols: Any letters appended may provide information about the heat treatment (e.g., “H” for hardened) or the mechanical properties (e.g., “Q” for quenched and tempered) of the steel.

An example of such a designation is “1.4301.” Here, the “1” stands for iron-based alloys, the “.4” for stainless steels, and the ‘301’ for the specific chemical composition of this steel, in this case a certain type of stainless steel (also known as “Edelstahl”).

It is important to understand that the material designation only provides an overview of the basic properties of the steel. For more detailed information, such as exact values for tensile strength, elongation, or hardness, refer to the manufacturer's material data sheet.

Knowledge of material designations is an essential tool for engineers, technicians, and anyone involved in the selection and processing of steel and other metals. It enables accurate identification of the material and helps to make the best choice for a specific application.

Werkstoffnummer

Comparison Table ANSI/ASTM /DIN

Trade Name Werkstoff
Nummer
Grade
S235JR 1.0037 S235JR
ST 52.3 1.0570 ST 52-3
CS (C22) 1.0402 C22
CS (C22.8) 1.0460
Low Temp CS 1.0508 TT St E 36
High Yield Steel
3.1/2 Nickel Steel 1.5639
5 Chrome 1/2 Moly 1.7362 12CrMo19.5
1.1/4 Chrome
1/2 Moly
1.7733
1.7335
24CrMoV-55
13 CrMo 44
2.1/4 Chrome 1/2 Moly 1.7380 10CrMo9.10
9 Chrome 1 Moly 1.7386
X12 Chrome 091 Moly 1.4903
13 Chrome
17-4PH 1.4542
153 MA 1.4818
201 1.4372
202 1.4371 X3CrMnNiN1887
248 SV 1.4418
253 MA 1.4835
254 SMo 1.4547
Trade Name Werkstoff
Nummer
Grade
301 1.4310 X12CrNi177
X10CrNi188
301LN 1.4318 X2CrNiN187
302 1.4300
1.4319
X12CrNi188
303 1.4305 X10CrNi189
304 1.4301 X5CrNi1810
X5CrNi189
304H 1.4948 X6CrNi1811
304L 1.4306
1.4307
X2CrNi1911
304LN 1.4311 X2CrNiN1810
305 1.4303
1.4312
X5CrNi1812
308 1.4303 X8CrNi1812
309 1.4828 X15CrNiSi2012
309S 1.4833 X7CrNi2314
310 1.4845
310L 1.4335 X1CrNi2521
310S 1.4845 X12CrNi2521
310 314 1.4841 X15CrNiSi2520
316 1.4401
1.4436
X5CrNiMo17122
X5CrNiMo17133
X5 CrNiMo1810
316Cb 1.4580 X6CrNiMoNb 17122
316F 1.4427 X4CrNiMoS1811
316H 1.4919 X8CrNiMo1712
Trade Name Werkstoff
Nummer
Grade
316L 316 316L 1.4404
1.4432
X2CrNiMo17132
X2CrNiMo17123
X2 CrNiMo1810
316LHMO 1.4435 X2CrNiMo18143
316LN 1.4429
1.4406
X2CrNiMoN17133
X2CrNiMoN17122
316Ti 1.4571 X6CrNiMoTi17122
317 1.4449 X5CrNiMo1713
317L 1.4438 X2CrNiMoN18164
317LNM 1.4434
1.4439
X2CrNiMoN17135
318 1.4583 X10CrNiMoNb 1812
321 1.4541 X6CrNiTi1810
    X10CrNiTi189
321H 1.4878 X12CrNiTi189
327 1.4821 X20CrNiSi254
329 1.4460 X4CrNiMo2751
330 1.4864 X12NiCrSi3616
347 1.4550 X6CrNiNb1810
    X10CrNiNb189
348 1.4546 X5CrNiNb1810
353 MA 1.4854
403 1.4000 X6Cr13
405 1.4002
1.4724
X6CrAI13
X10CrAI13
409 1.4512 X6CrTi12
Trade Name Werkstoff
Nummer
Grade
410 1.4006
1.4024
X12Cr13
X15Cr13
410S 1.4001 X7Cr14
414 1.4008 G-X8CrNi13
416 1.4005 X12CrS13
420 1.4021
1.4034
1.4028
X20Cr13
X38Cr13
420C 1.4034 X46Cr13
420F 1.4028 X30C13
422 1.4935 X20CrMoWV121
429   X10CrNi15
430 1.4016 X6Cr17
430F 1.4104 X12CrMoS17
430Ti 439 1.4510 X3CrTi17
431 1.4057 X20CrNi172
434 1.4113 X6CrMo171
440 444 1.4521 X2CrMoTi182
440A 1.4109
1.4110
X65CrMo14
X55CrMo14
440B 1.4112 X90CrMoV18
440C 1.4125 X105CrMo17
440F
442   X10Cr25
446-1 1.4749 X18CrN28
Trade Name Werkstoff
Nummer
Grade
630 (17-4PH) 1.4542 X5CrNiCuNb174
631 (17-7PH) 1.4568 X7CrNiAI177
633 (AM350)
634 (AM355)
654 SMo 1.4652
660 (A286) 1.4980 X5NiCrTi2515
904L 1.4539 X1NiCrMoCu 25205
AL-6XN®
Alu 6061 3.3211
Alu 5154 3.3635
Alu 5083
Carpenter 20
3.3547
2.4660

Cunifer® 10 2.0872 CuNi10Fe
Cunifer® 30 2.0882 CuNi30Fe
CU 5MCuC
Duplex 4462 1.4462 X2CrNiMoN2253
Ferralium® 255
Nicrofer 5923 hMo
(Alloy 59)
2.4605 NiCr22Mo
Nickel 200 2.4066
Nickel 201 2.4068
Magnesium 3.5312
Trade Name Werkstoff
Nummer
Grade
Monel® 400 2.4360
Monel R-405
Monel® K500 2.4375
Incoloy® 25-6MO 1.4529 X1NiCrMoCuN 25207
Incoloy® 800 1.4876 X10NiCrAITi3320
Incoloy® 800H 1.4958
Incoloy® 800HT 1.4959
Incoloy® 825 2.4858 NiFe30Cr21Mo3
Inconel® 600 2.4816
Inconel® 601
Inconel® 617
Inconel® 625 2.4856 NiCr22Mo9Nb
Inconel® 690
Inconel® 718
Inconel® X750 2.4669
Trade Name Werkstoff
Nummer
Grade
Hastelloy® B2 2.4617
Hastelloy® B3 2.4600
Hastelloy® C
Hastelloy® C22 2.4602 NiCr21Mo14W
Hastelloy® C276 2.4819
Hastelloy® C4 2.4610
Hastelloy® G
Hastelloy® G3
Hastelloy® G30
Hastelloy® X
SAF 2507 1.4469 G-X-25Cr7Ni4MoN
SAF 2304 1.4362
Sanicro® 28 1.4563
Ultimet 2.4681
Tantalum®
Titanium GR. 1 3.7025
Titanium GR. 2 3.7035
Titanium GR. 3 3.7055
Titanium GR. 5 3.7165
Titanium GR. 7 3.7235
Zirconium® 702
Zirconium® 705
Zeron 100 1.4501
Trade Name Werkstoff
Nummer
Grade


Some interesting facts

Duplex steels

Duplex steel refers to materials that have a two-phase structure (ferrite and austenite). Duplex steels are characterized by their combination of properties, which represent a mixture of the properties of stainless chromium steels (ferritic or martensitic) and stainless chromium-nickel steels (austenitic).

They have higher strengths than stainless chromium-nickel steels, but exhibit higher ductility than stainless chromium steels. Unlike pure austenites, they still exhibit fatigue strength when subjected to alternating stresses up to an austenite content of approx. 40%. Duplex steels are classified as rust- and acid-resistant steels.

Pitting Resistance Equivalent Number (PREN) index

The PREN index is a measure of the corrosion resistance of stainless steel. ASTM G48 specifies the test methods for this.

In corrosion-resistant steels, the chemical elements that are decisive for corrosion behavior are summarized by the PREN, which establishes a relationship between pitting resistance and chemical composition.

  • PREN = %Cr + 3.3 x %Mo (ferritic steels)
  • PREN = %Cr + 3.3 x %Mo + 16 x %N (austenitic steels)
  • PREN = %Cr + 3.3 x %Mo + 30 x %N (duplex steels)

Ferritic-austenitic duplex steels with PREN 40 are also referred to as super duplex steels and are characterized by particularly high corrosion resistance. Steels with PREN values above 32 are considered saltwater resistant.

Weldability of steels

Steels with a carbon content of more than 0.22% are only considered to be conditionally weldable; additional measures such as preheating are required. However, the carbon content of the steel alone does not determine its weldability, as this is also influenced by many other alloying elements. The so-called carbon equivalent is therefore taken into account for assessment purposes.

In materials science, the carbon equivalent is a measure used to assess the weldability of unalloyed and low-alloy steels. The carbon content and a variety of other alloying elements in steel influence its behavior. To assess weldability, the carbon content and the weighted proportion of elements that influence the weldability of the steel in a similar way to carbon are therefore combined into a numerical value in the carbon equivalent. A carbon equivalent value of less than 0.45% implies good weldability. Higher values require the material to be preheated, depending on the processing thickness. Above a value of 0.65, the workpiece is only weldable with increased effort, as martensite formation can lead to cold or hardening cracks.
